21.5" LCD Module with Touch (PCAP)

LCD Panel
Resolution:21.5" 1920 x 1080 (FHD)
White Luminance(w/ touch):≧210 (typ)cd/㎡
Viewing Angle:≧89/89/89/89
LED Life Time(Hrs):≧30,000
Interface:LVDS

Operating Temp.(℃):0~50
Touch
Touch Type:PCAP
Bonding Type:Air Bonding
Structure:G/G
Touch IC:EETI
Transparency:≧85%
Surface Hardness:≧6H
FPC Type:COB
Touch Interface:USB. I2C
Allow Touch Points:10 points
產品特性
廣視角
Full HD
其他說明



產品應用 Application





產品特色 Features





產品描述 Description



隨著科技的趨勢,顯示器的產品皆往可觸控領域發展,為人類帶來更便利的生活,
亦使得面板與觸控間有著密不可分的連結,我們採用穩定的IC以及貼合設備,來保持高良率與穩定的品質,
同時觸控功能需要專業人員校調分位,避免主板.驅動板等等的電器相互干擾,以達到最佳的使用體驗.
我們擁有專業的知識.技術與無塵室作業環境,為客戶帶來高可靠度的產品!
觸控面板適用於POS機.Gaming.IPC.HMI.KIOSK.KVM.筆電.強固型平板.自動化設備等各式互動環境.



21.5" Touch Display
Specification
Resolution (Pixels) 1920 x 1080 (FHD)
White Luminance ≧210 (typ)cd/㎡
Viewing Angle 89/89/89/89
LED Life Time(Hrs) ≧30,000
Interface LVDS
Touch Type PCAP
Bonding Type Air Bonding
Touch Structure
G/G
Touch IC EETI
Sufrace Hardness  ≧6H
FPC Type COB
Allow Touch Points 10 Points
Touch Interface USB / I2C
Operating Temperature 0~50 ℃

可選配件 Optional Accessories



AD-0037 LCD Control Board



● Support to 1920x1080 @60 Hz


● Signal Input:HDMI.VGA.DP.Audio Phone Jack


● Signal Onput:Dual Port 6/8 bits LVDS

● On-board Realtek solution offers top notch reliability, precision, and robustness.
● We provide detailed technical parameters for best performance.
● Offer in-box packaging services for cables including OSD Key Cable, Panel Cable, and Backlight Cable.
