10.1" F101RET-Z01 LCD Module with Touch (RTP)

LCD Panel
Resolution:10.1" 1280 x 800 (WXGA)
White Luminance(w/ touch):≧280 (typ)cd/㎡
Viewing Angle:≧85/85/85/85
LED Life Time(Hrs):≧20,000
Interface:LVDS

Operating Temp.(℃):-10~60
Touch
Touch Type:5 Wires RTP
Bonding Type:Air Bonding
Structure:F/G
Touch IC:EETI
Transparency:≧80%
Surface Hardness:≧3H
FPC Type:COB
Touch Interface:USB
產品特性
廣視角
